l Dimensions:220*60*35mm

l 12 double speed reset button

l Weight: 450g

l Current consumption: operating on average 3.75ma

l Continue working time: 60 hours

l Start：press start button for 2s

l Antenna：internal

l Emergency stop：Conforms to EN13849-1 standard

l Enclosure material ：PA6+30%GF with rubber cover

l Protection degree： IP65 (Enclosure type 4)

l Power supply: Rechargeable lithium-ion battery with a capacity of 1000mAh

l Buttons life: More than 5 million times

l Humidity range: 0 - 97% maximum non-condensing

l Center frequency range: 433-434Mhz

l Response time: Less than 100ms

l Safety: Active and passive Stop function, Parity & Checksum

l Power (RF Output): 10mW(e.r.p)

l Baud rate: 19200Kbps

l Approximately operating range: 100m(328ft)

l Temperature range: -25℃~+70℃ (-13°F to +158°F)

l Button text: options of arrow, English text, symbol or customize

l Receiver: R20
